XCM/XCH(4m³/H)
Pump body: AISI304 SS
Pump support: Aluminum
Motor housing: Aluminum
Impeller: Brass, AISI304 SS if request
Diffuser: Noryl
Motor shaft: AISI304 SS
Mechanical seal: SIC/Graphite
Application
Suitable for use with clean water and liquids that are not chemically aggressive towards the materials from which the pump is made.
The self-priming jet pumps are designed to pump water even in cases where air is present. As a result of their reliability and the fact that they are easy to use, they are recommended for use in domestic applications such as the distribution of water in combination with small or medium sized pressure setsand for the irrigation of gardens and allotments, etc.
The pump should be installed in an enclosed environment or at least sheltered from inclement weather.
Motor
※Two-pole induction motor(n=2850 r.p.m)
※Insulation Class B
※Protection IP44
※Continuous service S1
※Thermal protector for single phase
※Single-phase 220V/50Hz,60Hzifrequest
Three-phase 380V/50Hz, 60Hz if request
Operating conditions
※Liquid temperature up to 60℃
※Ambient temperature up to 40℃
※ Total suction lift up to 9m
