ASPRI
Pump body: Cast iron + Stainless steel
Pump support: Castiron
Motor housing: Aluminum
Impeller: AISI304 SS, PPO if request
Motor shaft: AISI304 SS
Mechanical seal: SIC/Graphite
Application
Suitable for use with clean water even where air is present and with liquids that are not chemically aggressive towards the materials from which the pump is made.
The pumps are designed to pump water even in cases where air is present. As a result of their quietness,reliability and low energy consumption they are recommended for use in domestic and civil applications such as the pressu-risation and distribution of water in combination with pressure sets, and in rain water recovery and irrigation systems, etc.
The pump should be installed in an enclosed environment, or at least sheltered from inclement weather.
Motor
※ Two-pole induction motor(n=2850 r.p.m)
※Insulation Class B
※Protection IP44
※Continuous service S1
※Thermal protector for single phase
※Single-phase220V/50Hz, 60Hz if request
Three-phase 380V/50Hz, 60Hz if request
Operating conditions
※Liquid temperature up to 60℃
※Ambient temperature up to 40℃
※ Total suction lift up to 8m
