Jet pump
Pump body: Cast iron
Motor bracket: Cast iron
Impeller: Brass
Motor shaft: SS304 or CS#45
Mechanical seal: Ceramic and graphite
Bearing: Normal or C&U
Detail
OPERATING CONDITIONS
oLiquid temperature up to 60°C
Ambient temperature up to 40°℃
Total suction ilft up to 8m
MOTOR INFORMATION
Two-pole induction motor
Single-phase 220V/50Hz 220V/60Hz 110V/60Hz
Thermal protector for single-phase
Continuous duty
oInsulation calss:B
oProtection:IP44
