Jet Pump
Pump body: Castiron
Motor bracket: Aluminium
Impeller: Techno-polymer(PPO/PC)
Ejector: PC or PPO
Motor shaft: SS304 or CS#45
Mechanical seal: Ceramic and graphite
Bearing: Normal or C&U
Detail
OPERATING CONDITIONS
Liquid temperature up to 60°C
Ambient temperature up to 40°C
Total suction ilft up to 8m
MOTOR INFORMATION
Two-pole induction motor
Single-phase 220V/50Hz 220V/60Hz 110V/60Hz
Thermal protector for single-phase
Continuous duty
Insulation calss: B
Protection:IP44
