4SDM2
Delivery case: Brass
Pump body: AISI 304 SS
Motor bracket: AISI 304 SS
Pump surpport: Brass
Impeller: Plastic POM
Diffuser: Plastic PC
Shaft: AISI 304 or 316 SS
Bearing: Normal,C&U,NSK
WORKING CONDITON
Max.submerged depth:80m
Fluid temperature up to +40℃
Max ambient temperature +40℃
Max sand content:0.25%(50g/m)
Mini well Diameter:4"
APPLICATION
The pumps are suitable for continuous and intermittent operation, they are used for
Domestic water supply
Wells and reservoirs
Industrial applications
Pressure boosting
Garden spraying and farm irrigation
MOTOR&PUMP
Rewindable motor
Single-phase 220V-240V/50Hz,60Hz
Three-phase:380V-415V/50Hz,60Hz
Equipped with Start Control Box or digital auto-control box
Continous duty
